House Floor Plan Overall Layout and Dimensions, let’s break down the provided floor plan image and analyze it step by step. We’ll cover everything from overall layout to specific room dimensions and elements.
Overall Layout and Dimensions
- Shape: The overall shape of the plan is rectangular. The external dimensions are clearly given which is 5.85 m by 6.15m.
- Total Area: The total area of the apartment is the product of the two given values which is 5.85m x 6.15m = 35.9775 square meters.
- Internal Layout: The internal space is divided into several functional areas. These are two bedrooms (DORMITORIO), a bathroom (BAÑO), a kitchen (COCINA), and a living room (SALA).
Detailed Room Analysis
- Bedrooms (DORMITORIO):
- Number: There are two bedrooms. They are on the left side of the floor plan, one above the other.
- Upper Bedroom:
- Dimensions: The upper bedroom has internal dimensions of 2.40m by 2.10m.
- Furniture: The furniture in the upper bedroom includes a bed drawn with a headboard and a small furniture piece to the left of the bed.
- Lower Bedroom:
- Dimensions: The lower bedroom has an internal dimension of 2.85m by 3.00m.
- Furniture: The lower bedroom contains a bed and an unknown object opposite the bed (could be a mirror or another furniture piece).
- Windows: Both bedrooms appear to have exterior-facing windows.
- Bathroom (BAÑO):
- Dimensions: It has internal dimensions of 1.35m by 0.90m.
- Fixtures: The bathroom contains a toilet, a shower, and a sink.
- Access: Access to the bathroom is through a door between the upper bedroom and the kitchen area.
- Kitchen (COCINA):
- Dimensions: The kitchen occupies a space adjacent to the bathroom, with an irregular shape.
- Features: The kitchen contains a stove, a sink, and a refrigerator marked as “REF.”.
- Access: Access to the kitchen is through the door on the right and connects the kitchen to the living room.
- Living Room (SALA):
- Dimensions: The living room occupies the remaining space to the right of the floor plan, with an irregular shape.
- Features: The living room has furniture that includes a sofa and some additional seating.
- Access: Access to the living room is from the door at the center, and opens to the corridor that connects to the bedrooms.
Doors and Hallways
- Main Access: The main access to the apartment is not directly seen but based on the internal layout, the most probable access point is either directly to the sala, or to the hallway in the center.
- Door Sizes: Most doors are represented as having a 0.90m width.
- Hallway: The space in the center acts as a hallway connecting to the rooms of the house.
Detailed Measurements and Analysis
- External Walls: The building’s exterior walls are shown with a line symbol, and all the given dimensions are for the exterior of the walls.
- Internal Walls: The internal walls are represented as a line symbol, that separates the different rooms. The measurements are to the interior walls of the room.
- Room Sizes: The bedrooms are both a good size for a bedroom, with enough room to fit basic furniture. The bathroom and the kitchen are compact and efficient with the way the elements are placed within them.
- Door Widths: The doors are all standard sizes, which make it easy to maneuver around the home.
- Spatial Flow: The layout is designed to optimize the use of space, with minimal unused space and a natural flow between the different areas.
Additional Notes and Observations:
- Scale: While not explicitly stated, it’s reasonable to assume the floor plan is drawn to a consistent scale given the consistent dimensions and the fact that it is a floor plan.
- Symbols: Standard architectural symbols are used, such as the lines used for walls and fixtures for the bathroom and kitchen.
- Orientation: No orientation of north is given.
- Accessibility: The door widths of 0.90m may be too small for people with mobility issues.
- Window Placement: The placement of windows will impact the amount of natural light that comes into the rooms.
- Clearance: Clearances have not been shown, if we were to look at a full design we would look at the clearances of fixtures like the doors, the toilet and the shower.
Summary of Key Features:
- Compact Design: The plan represents a small compact home, and is designed for efficiency.
- Functional Zones: The division of space into bedrooms, living, kitchen, and bathroom is practical and functional.
- Clear Dimensions: The consistent usage of dimensions makes the floor plan accurate and allows accurate measurements to be taken.
- Minimal Hallway: The hallway is minimal to not waste too much space in the layout.
This comprehensive analysis should provide a good understanding of the provided floor plan. If there’s any specific area you’d like me to focus on or any other questions you have, feel free to ask!
